Intro To Engineering

Welcome To Class!

Today we are going to Make a doorstop as we learn more about:

• Sketches
• Extrusions
• Chamfers
• Offset
• Emboss
• Draft
• Make a customized drawing templte

Click HERE for the slide show to get instructions and video for today's assignment.

Make sure to finish up Fusion assignments and update Week 7 in your Portfolio:

• • Mon - Tues no school
  • Wed- Screenshot of Holes Activity
  • Thur- Screenshot of Shapes/Rod Activity
  • Fri - Doorstop
  • At least 1 Full sentence about what you did in class each day

Welcome To Class!

1) Finish FUSION HOLES Activity:

• Click HERE to view the slides we went through in class to take notes.
• Click HERE to go to the video that walks you through how to do today's assignment.
• When finished make a multiview of your holes with dimensions, take screenshot to add to your portoflio

2) Next, we are going to practice on FUSION, click HERE to get slides with instructions and video to help you do the following:

• sketching shapes to specific dimensions

• Adding through holes to shapes

• Assembling shapes on a rod

Welcome to Class!

Today in class we are starting with a MULTIVIEW QUIZ ... get out a pen/pencil.

How do you create different HOLES in Fusion?

Start FUSION HOLES Activity:

• Click HERE to view the slides we went through in class to take notes.
• Click HERE to go to the video that walks you through how to do today's assignment.
